Performance and Characteristics:
1. It adopts the microcomputer contact screen to control, three-phase mixing motor to pull material; and producing piece number can be set up freely.
2. It is suitable for all kinds of molds, easy operation.
3. It is suitable for producing HDPE and LDPE film into the glove, which widely used in medical, restaurant, and food filed for its convenience and healthy.
主要技术参数 Main Technical Variables:
| 型号Model | DHB-500 |
| Glove mould size | 36.5×39cm |
| Glove Making Speed | 50-250Pcs/Min/Layer |
Film roll unwinding device | Quantity: 2sets, with mechanical shaft Tension Controller: 2.5KG magnetic barker with manual controller With raw material tracking photocell: stop automatically when raw material out. |
| Unwinding motor | Unwinding motor: 0.55KW, with 1.1KW inverter Quantity: 2 sets Controlling: main computer controlling. |
| Main driver | Structure: crank rocker push-pull structure Drive: A.C motor with inverter controlled, 1.1 KW Controlling: main computer controlling. |
| Front Traction motor | Structure: Friction type, Drive: Step motor, SONGYANG Transmission: M-type synchronous belt wheel drive, Control form: step motor driver-ZHONGXIN Detection method: photocell combined with proximity switch |
| Glove mould | Quantity: 2 pcs, Raw material: Cast copper Heating: heating pipe, with temperature controller, control temperature automatically. |
| Cutting knife | Quantity: 1 set Width: 380mm Material: White Steel Alloy Drive mode: main motor connecting rod drive |
| Electric Cabinet | |
| Other | Tracking photocell: 1 set Static Eliminator: dry type, elimination bar * 2, elimination device * 1 Conveyor belt: 1 set |
| Weight | 600KG |
| Outline dimension(L×W×H) | 3500×1050×1850mm |
|
|
