QUALITY FIRST,DARE TO INNOVATE
6 Years
| Ask Lasest Price | |
| Brand Name : | aotong |
| Model Number : | KZJ |
| Certification : | CE,ISO |
| Price : | USD8000-10000 |
| Payment Terms : | L/C, T/T, Western Union, MoneyGram |
| Supply Ability : | 500 SET |
| Delivery Time : | 20-30 DAYS |
1.Featrues:
Compact structure, stable function and simple operation.
Double frequency converter controller,length of package will cut
immediately once setting, adjustment needless, saving time and
film.
It adopts imported electric appliance, touch manmachine interface,
convenient parameter setting.
Self-cheching function, trouble can be read easily. High sensor
photoelectric color chart tracking, make the cutting position more
correctly.
Dependant temperature PID controlling suitable for various
materials of packagingmenbrane.Position stop function, no adhesive
and no waste of membrane.
Clean rotation system, more reliableoperation and more convenient
maintenance.
All the controlling operates by the software,convenience for
function ad-justment and technical up grading.
2.Main Technical Data
| Type | AT-250 | AT-350 | AT-450 | AT-600 |
| Film width | 250MM | 350MM | 450MM | 590MM |
| Bag Length | 65-330MM | 65-330MM | 110-350MM | 150-400MM |
| Bag width | 30-120mm | 30-150MM | 50-200MM | 50-270MM |
| Products High | Max.45mm | Max.50mm | Max.80mm | Max.100mm |
| Packing speed | 40-220bag/mins | 40-220bag/min | 40-180bag/min | 50-120bag/min |
| Power | 220V 50/60HZ 2.4KW | 220V 50/60HZ 2.4KW | 220V 50/60HZ 2.7KW | 220V 50/60HZ 4.2KW |
| Machine size | 4000x920x1500 MM | 4100x1050x1560 MM | 4100x1050x1560 MM | 4200x1200x1750 MM |
| Machine Weight | 500kg | 600kg | 680kg | 780kg |
Contact person : Lucy
Mobile:0086-13706885479
|
|
